Key Engineering Features
- ✓Heavy-duty cast iron bow structure absorbs cutting vibration
- ✓Hydraulic vise clamping and stepless hydraulic downfeed regulation
- ✓Carbide blade guides with roller bearings for extended blade life
- ✓Integrated flood coolant system with chip collection tray
BS-400 Semi-Automatic Horizontal Band Saw Machine
Heavy cast-iron saw frame with hydraulic blade tensioning and automatic downfeed
The BS-400 is an industrial horizontal metal cutting band saw designed for solid steel bars, heavy pipes, and profile cutting up to Ø400mm. Features hydraulic vise clamping, variable blade speed, and automatic cut-off shutoff.
Includes ISO/CE quality test certificate, operation manual, tooling accessories, and 24-month manufacturer warranty.
Full Technical Specifications (BS-400)
Factory certified parameters tested according to international machine tool standards.
| Max Round Cutting Capacity | Ø400 mm |
| Max Rectangular Cutting Capacity | 400 x 400 mm |
| Blade Dimensions | 4570 x 34 x 1.1 mm |
| Blade Speed | 20, 40, 60, 80 m/min |
| Main Motor Power | 4.0 kW (5.5 HP) |
| Hydraulic Motor Power | 0.75 kW |
| Coolant Pump | 0.12 kW |
Standard Included Equipment
- ✓Bi-metal saw blade
- ✓Hydraulic clamping vise
- ✓Roller stock feed conveyor (2m)
- ✓Flood coolant pump
- ✓Halogen work light
Optional Accessories & Upgrades
- +Automatic chip conveyor
- +Hydraulic top bundle clamping
- +Digital angle readout (0°-45° mitering)
- +Laser line projection
