Key Engineering Features
- ✓Induction hardened and precision ground Meehanite flat bedways
- ✓8-station servo/hydraulic turret for quick tool indexing in 0.3s
- ✓Heavy-duty hydraulic power chuck and programmable hydraulic tailstock
- ✓High-precision C3 ballscrews with preloaded angular contact bearings
CK-6150 High-Rigidity CNC Lathe Machine
Heavy induction hardened bedways, 8-station hydraulic turret and Ø82mm spindle bore
The CK-6150 is a heavy-duty CNC turning machine engineered for high-precision shafts, flanges, and threading operations. Features induction hardened and ground flat bedways, powerful 7.5kW servo spindle drive, and hydraulic power chuck.
Includes ISO/CE quality test certificate, operation manual, tooling accessories, and 24-month manufacturer warranty.
Full Technical Specifications (CK-6150)
Factory certified parameters tested according to international machine tool standards.
| Max Swing Over Bed | Ø500 mm |
| Max Turning Length | 1000 / 1500 mm |
| Spindle Bore Diameter | Ø82 mm |
| Spindle Nose & Speed | ISO A2-8 / 50-2500 RPM |
| Main Spindle Motor | 7.5 / 11 kW (Servo) |
| Tool Post / Turret | 8-Station Hydraulic |
| Tailstock Quill Taper | Morse No. 5 (MT5) |
Standard Included Equipment
- ✓10" Hydraulic 3-jaw chuck
- ✓8-station hydraulic turret
- ✓Hydraulic tailstock
- ✓Automatic lubrication pump
- ✓Full splash enclosure
Optional Accessories & Upgrades
- +Automatic bar feeder interface
- +Hollow hydraulic cylinder
- +Automatic tool setter arm
- +Automatic chip conveyor
